RACB Motor
RACB Motor
| Model | Rated Voltage | No-load Speed / Current | Rated Speed / Torque / Current | Stall Torque / Current | Output Power |
|---|---|---|---|---|---|
| TFC3625-0630 | 6VDC | 3000 r/min / 210mA | 2100 r/min / 100g.cm / 400mA | 340g.cm / 1.8A | 2.2W |
| TFC3625-1255 | 12VDC | 5500 r/min / 180mA | 4600 r/min / 84g.cm / 800mA | 140g.cm / 1.6A | 4.6W |
| TFC3625-2480 | 24VDC | 8000 r/min / 160mA | 5900 r/min / 270g.cm / 900mA | 680g.cm / 2.0A | 16.5W |
Automatic door operators, automatic energy saving bath, electrical controlled valve, robots, grass cutter, electric curtain, camera, medical service, oxygen machine, etc.
| Business Machines | Camera and Optical | Lawn and Garden |
|---|---|---|
| Vending Machines | Video Cameras | Lawn Mowers |
| Printers | Projectors | Snow Blowers |
| ATM | Optical Systems | Trimmers |
| Copiers and Scanners | - | Leaf Blowers |
ISO9001, SGS, National high-tech enterprises, etc.
Our company has been specializing in micro motors, gear motors and their respective parts since 2000. Our products are widely used in entertainment systems, automobiles, home and industrial appliances and tools and many others. Our products are dependable and long-lasting, and backed by years of experience. We export 98% of our output worldwide. By leveraging our hard-won reputation for honesty, dependability and quality, we aim to continue as a pioneer in the sales overseas by seeking global partners. If your company is an end-user of micro-motors, a distributor or an agent, please contact us. We look forward to being able to work together with you in the near future.
NIKE, FLEXTRONICS, STANLEY, etc.
Standard packing
Excellent quality, better price, good service, and on time delivery.
